GNEE Aluminum is dedicated to offering high-quality aluminum tube products. Our aluminum tubes are available in a variety of standards and alloys, making them useful for a wide range of industries like construction, aviation, and automotive.
We offer tens of thousands of tons of aluminum tubes in stock, accurate estimates, timely delivery, and bespoke modification services to satisfy the diverse needs of our customers.
Types of aluminum tubes we offer
GNEE Aluminum can supply the six standard aluminum pipe types, which are defined by their manufacturing processes:
Aluminum Extruded Tube
Pipe formed by hot extruding.
Outer diameter range:2-1000mm
Wall thickness range:0.5-50mm
Surface: mill finish, polished, anodized
Drawn Aluminum Tube
Pipe brought to final dimensions by drawing through a die.
Outer Diameter: 5-220 mm ± 0.1 mm (Tolerances)
Wall Thickness: 0.5-10 mm ± 0.05 mm (Tolerances)
Standard: EN 754, ASTM B234M, GB/T 5237-2008
Seamless Aluminum Tubes
Pipe that does not contain any line junctures (metallurgical welds) resulting from the method of manufacture. (Note: This product may be produced by extruding or by drawing, using either die-and-mandrel or hot piercer processes.)
Welded Aluminum Tube
Reliable and cost-effective, our welded aluminum tubes are ideal for structural and low-pressure systems-custom sizes available; contact us for a quick quote!
Precision Aluminum Tube
Outer Diameter: 3mm - 220mm
Wall thickness: 0.3mm - 10mm
Length: 3 m, 4 m, 6 m (customizable)
Anodized Aluminum Tube
Durable, corrosion-resistant, and available in various finishes-perfect for decorative and industrial use. Contact us for custom orders!
Aluminum tube shapes GNEE can manufacture
Popular aluminum alloys for tubes and pipes
1000 series aluminum tubes
The 1000 series aluminum tubes offered by GNEE are based on high-purity aluminum and possess excellent corrosion resistance, thermal and electrical conductivity, and superior formability. Grade: 1050, 1060, 1100, etc. Temper: O/H14/H18/H19/H16
1050 aluminum tube
1050 aluminum tube is a standard high-purity aluminum tube with good corrosion resistance and formability, suitable for general industrial and decorative applications.
1060 aluminum tube
1060 aluminum tube has a higher purity than 1050 aluminum tube, offering better electrical and thermal conductivity, making it suitable for heat transfer and electrical applications.
1100 aluminum tube
1100 aluminum tube contains trace amounts of alloying elements. Compared to 1050/1060 aluminum tubes, 1100 tubes have improved strength and weldability while maintaining excellent corrosion resistance and machinability.
2000 series aluminum tubes
High-strength, heat-treatable 2-series aluminum alloy tubes possess excellent mechanical properties and fatigue resistance, but their corrosion resistance is lower than that of pure aluminum alloys. Grade: 2024/2014/2011/2219/2A11/2A12/2A14, etc. Temper: O/T64/T6/T3/T451/T651
2011 Aluminum Tube
An easily machinable aluminum alloy with excellent processing performance, 2011 aluminum tubes are ideal for precision-machined parts but are not suitable for welding applications.
2014 Aluminum Tube
Stronger than 2024 and with better machinability, 2014 aluminum tubes are suitable for heavy-duty structures and forging applications.
2024 Aluminum Tube
2024 aluminum tube is a high-strength Al-Cu-Mg alloy with excellent fatigue resistance, widely used in aerospace structural components.
2219 Aluminum Tube
Possessing excellent high-temperature strength and superior weldability, 2219 aluminum tubes are commonly used in aerospace and cryogenic structures.
2A12 Aluminum Tube
A high-strength structural alloy, similar to 2024 but with slightly improved toughness, 2A12 aluminum tubes are widely used in aerospace and military fields.
2A14 Aluminum Tube
An ultra-high-strength Al-Cu-Mg-Si alloy with excellent heat resistance, 2A14 aluminum tubes are designed for heavy-duty and high-temperature environments.
3000 series aluminum tubing
3000 series aluminum alloys are non-heat-treatable aluminum-manganese alloys, known for their good corrosion resistance, moderate strength, and excellent formability. 3000 series aluminum tubing is an ideal choice for general-purpose and heat exchange applications. Grade: 3003/3004/3005/3105, etc. Temper: O/H14/H18/H24/H34/H38/H36
3003 Aluminum Tube
The most commonly used 3xxx series alloy, with good corrosion resistance and excellent formability. 3003 aluminum tubing is suitable for a variety of general manufacturing applications.
3004 Aluminum Tube
Due to the addition of magnesium, it has higher strength than 3003. 3004 aluminum tubing is suitable for applications requiring higher load-bearing capacity.
3005 Aluminum Tubing
Higher strength than 3003 and better formability. 3005 aluminum tubing is often used in construction and structural tubing.
3105 Aluminum Tubing
Lower strength, but better surface finish and corrosion resistance. 3105 aluminum tubing is an ideal choice for decorative, coating, and painting applications.
5000 series aluminum tubes
Aluminum-magnesium alloys offer excellent corrosion resistance, good weldability, and medium to high strength. 5000 series aluminum tubes are particularly suitable for marine and corrosive environments. Grade: 5052/5083/5086/5005/5251, etc. Temper: O/H112/H32/H34/H36/H38/H321/H116/H112/H111
5052 Aluminum Tubes: A medium-strength alloy with excellent corrosion resistance and outstanding formability, 5052 aluminum tubes are ideal for fuel lines, pressure tubing, and general manufacturing.
5083 Aluminum Tubes: A high-magnesium alloy with extremely high strength and excellent resistance to seawater corrosion, 5083 aluminum tubes are widely used in ships and marine structures.
5086 Aluminum Tubes: Slightly lower strength than 5083, but with better formability, 5086 aluminum tubes are often used in shipbuilding and transportation pipelines.
5005 Aluminum Tubes: A low-magnesium alloy with good corrosion resistance and excellent anodizing properties, 5005 aluminum tubes are ideal for decorative and architectural applications.
5251 Aluminum Tubes: Higher strength than 5052, with good corrosion resistance and fatigue resistance, 5251 aluminum tubes are suitable for structural and marine-related applications
6000 Series Aluminum Tubes
These are heat-treatable Al-Mg-Si alloys that combine good strength, corrosion resistance, weldability, and excellent extrusion properties. 6000 series aluminum tubes are suitable for structural and architectural applications. Grade: 6061/6063/6082/6060, etc. Temper: O/T4/T5/T6/T651/H112/H32
6061 Aluminum Tube
The most common alloy in the 6xxx series, offering higher strength and good machinability. 6061 aluminum tubes are widely used in structural, mechanical, and load-bearing applications.
6063 Aluminum Tube
Compared to 6061, it has lower strength but better surface finish and extrusion properties. 6063 aluminum tubes are an ideal choice for architectural and decorative tubing.
6082 Aluminum Tube
The strongest alloy in the 6xxx series, 6082 aluminum tubes provide excellent structural performance for heavy-duty and engineering applications.
6060 Aluminum Tube
Similar to 6063, but with slightly lower strength and better extrusion properties and surface quality. 6060 aluminum tubes are the preferred choice for thin-walled and precision profiles.
7000 Series Aluminum Tubes
Heat-treatable Al-Zn-Mg(Cu) alloys are renowned for their extremely high strength and fatigue resistance, and 7000 series aluminum tubes are primarily used in aerospace and high-performance structural applications. Grade: 7075/7005/7050/7046, etc. Temper: O/T6/T73/T76/T7351/T651
7075 aluminum tube: An ultra-high-strength alloy with excellent fatigue resistance, 7075 aluminum tubes are commonly used in aerospace and high-stress structural components.
7005 aluminum tube: A medium-to-high-strength alloy with good weldability and corrosion resistance, 7005 aluminum tubes are widely used in transportation and bicycle frames.
7050 aluminum tube: Offers better stress corrosion cracking resistance and toughness than 7075 alloy; 7050 aluminum tubes are specifically designed for thick-section aerospace structures.
7046 aluminum tube: A high-strength alloy similar to 7075 alloy, but with optimized fracture toughness and fatigue performance for critical aerospace applications.
