6063 Aluminum Plate: Properties, Tempers and Applications

Jan 09, 2026

What Makes 6063 Aluminum Plate Distinctive

6063 is a heat-treatable 6000-series alloy whose main additions are magnesium and silicon. Compared with 6061 it contains noticeably less of both, so its strength is roughly half, yet the trade pays off in form: 6063 extrudes and rolls to a smoother, brighter surface with fewer die lines, takes a deeper and more uniform anodic coating, and welds cleanly.

The plate form is supplied in the T5, T6 and T651 tempers for machined parts, jigs, frames and architectural components that need a good surface finish more than maximum load capacity. Its thermal plasticity is high, which is why complex profile cross-sections are so often specified in this alloy.

Tempers Normally Stocked

T5 - cooled from the hot forming temperature and then artificially aged. The standard temper for extruded architectural profiles and general fabrication; excellent surface finish at moderate strength.

T6 - solution heat treated and then artificially aged. The strongest of the common 6063 tempers, used where higher load capacity or better wear behaviour is needed.

T651 - T6 followed by stress relief by stretching. Preferred for thick plate that must remain flat after heavy machining.

O and T4 - soft, highly formable conditions used where the part is bent or shaped before aging.

Mechanical Properties

Temper Tensile strength Yield strength, 0.2% offset Elongation in 50 mm Brinell hardness
6063-T5 186 MPa (27,000 psi) 145 MPa (21,000 psi) 12% 60
6063-T6 241 MPa (35,000 psi) 214 MPa (31,000 psi) 12% 73
6063-T651 241 MPa (35,000 psi) 214 MPa (31,000 psi) 12% 73

Typical physical values for the alloy are a density of 2.70 g/cm3, an elastic modulus of about 68.9 GPa and a melting range of roughly 615-655 C. The lower melting range relative to 6061 reflects the higher magnesium content and is favourable for extrusion, though it also means heat input during welding must stay controlled.

Equivalent Grades and Applicable Standards

System Designation
UNS A96063
EN / ISO EN AW-6063, AlMg0.7Si (formerly AlMgSi0.5)
DIN / WNR 3.32206
BS (historical) HE9
AA 6063
China 6063 (previous designation LD31)

Product is normally certified to ASTM B209 for sheet and plate, ASTM B221 for extruded bar, rod, tube and profile, ISO 6362 and GB/T 6892 for extruded products, and GB/T 5237 where the material is destined for architectural profiles. Chemical composition is verified against EN 573-3, ISO 209 and GB/T 3190, and temper designations follow ANSI H35.1. Buyers should state the standard, temper and mechanical table that apply, since the same alloy is offered under several national specifications.

Supply Range, Processing and Applications

6063 aluminum plate is commonly offered in thicknesses from 0.5 mm to 300 mm, widths from 100 mm to 2,800 mm and lengths of 1,250 mm, 2,000 mm, 2,440 mm, 2,500 mm or 6,000 mm, with cut-to-size service for other dimensions. Surface options include mill finish, brushed, mirror, embossed, anodized and powder coated. In-house processing covers bending, welding, punching and CNC cutting.

Construction - door and window frames, curtain wall mullions, ceilings and stair handrails, where light weight and a clean anodized finish matter.

Automotive and transport - trim, interior panels and lightweight structural details that benefit from the alloy's formability.

Shipbuilding - superstructure and interior fittings that need good resistance to marine air without the weight of steel.

Electronics - enclosures, heat sinks and chassis parts, taking advantage of high thermal conductivity and easy anodizing.

Precision machinery and instruments - covers, guards, cable ducts and machine parts where a smooth, dimensionally stable surface is required.

Furniture, display and sports equipment - frames, tubing and hardware that are visible in service and expected to stay attractive.

FAQ

Q: Is 6063 plate as strong as 6061 plate?
No. In comparable tempers, 6063 is around half as strong in yield because it contains less magnesium and silicon. 6061 is the better choice when the part carries structural load.

Q: Which temper should be specified for anodized architectural work?
T5 is the usual choice. It anodizes to a uniform, bright film, holds tolerances well when extruded or rolled, and provides adequate strength for windows, curtain walls and handrails.

Q: Can 6063 plates be welded?
Yes. The alloy has very good weldability by TIG and MIG, and it is one of the few structural aluminum materials that can be welded without a dramatic loss of joint integrity, though filler alloy selection still matters.

Q: Why specify T651 instead of T6 for thick plate?
T651 applies stretching after aging, which removes most residual stress. Thick sections then machine flatter and stay flatter, which is critical for moulds, jigs and inspection fixtures.

Q: What surface finishes are available on 6063 plate?
Mill finish, brushed, mirror polished, embossed, anodized and powder coated are all standard. Anodized finishes can be clear or dyed to a specified colour, with coating thickness agreed against the applicable anodizing standard.

Q: Is 6063 suitable for heat sinks?
Yes. The alloy combines high thermal conductivity with easy extrusion and machining, and anodizing adds a hard, corrosion-resistant surface that also suits electrical insulation requirements.
